MOGAMI W3172 High-Definition Tube Microphone Cable
MOGAMI W3172 High-Definition Tube Microphone Cable - Image 2

MOGAMI W3172 High-Definition Tube Microphone Cable

Call For Price

Found this product at a lower price?
  Check Stock & Price

Tube Microphone Cable

SKU: W3172 Category:
Description

Description

Part No.
W3172
No. of Conductor 6 Signal Assignment
Conductor Details 2 × (30/0.08 OFC) MIC. OUTPUT
Size(mm²) 0.15mm² (#26AWG)
Insulation Ov. Dia.(mm) 1.0Ø (0.039″)
Material XLPE
Colors Orange / White
Conductor Details 2 × (75/0.04 Cu-Sn) BIAS
Size(mm²) 0.094mm² (#28AWG)
Insulation Ov. Dia.(mm) 1.0Ø (0.039″)
Material XLPE
Colors Red / Purple
Conductor Details 2 × (80/0.08A) HEATER CIRCUIT
Size(mm²) 0.40mm² (#22AWG)
Insulation Ov. Dia.(mm) 1.6Ø (0.063″)
Material PVC
Colors Green / Blue
Served Shield Double Served Shield Approx. 112/0.10A and Approx. 133/0.10A

Binder

 Thickness 0.025mm (0.00098″)
Material Paper Tape
Ov. Jacket Ov. Dia.(mm) 6.5Ø (0.256″)
Material Flexible PVC
Color Black
Roll Size 100m (328Ft)
Weight per 100m Roll 6.3kg

ELECTRICAL & MECHANICAL CHARACTERISTICS

Part No.
W3172
DC Resistance at 20°C Inner Conductor MIC SIGNAL 0.13Ω/m(0.040Ω/Ft)
BIAS CIRCUIT 0.23Ω/m(0.070Ω/Ft)
HEATER CIRCUIT 0.046Ω/m(0.014Ω/Ft)
Shield 0.011Ω/m(0.0034Ω/Ft)
Capacitance at 1kHz, 20°C Shield-Conductor 230pF/m(70pF/Ft) 100pF/m(30pF/Ft) 93pF/m(28pF/Ft)
between neighbour conductors “TWISTED PAIR” 56pF/m(17pF/Ft) 46pF/m(14pF/Ft) 137pF/m(42pF/Ft)
Inductance “TWISTED PAIR” 0.4µH/m(0.12µH/Ft)
Electrostatic Noise* “TWISTED PAIR” 1mV Max.
Electromagnetic Noise at 10kHz* “TWISTED PAIR” 0.01mV Max.
Microphonics* “TWISTED PAIR” 10mV Max.
Voltage Breakdown Must withstand at DC 500V/15sec.
Insulation Resistance 100000 MΩ × m Min. at DC 125V, 20°C
Flex Life* 13,000 cycles
Tensile Strength 588N
Emigration Non-emigrant to ABS resin
Applicable Temperature -20°C‾ 70°C(-4°F‾ 158°F)
Additional information
Weight 6 g
Dimensions 40 × 40 × 27 mm
