- 1600 W (peak), 133 dB peak SPL utilizing high sensitivity transducer designed and engineered by EV for maximum punch.
- High-output EVS-18L woofer designed to exacting specifications for superior durability and exceptional low-frequency reproduction.
- System reliability verified with over 500 hours of abuse testing and endurance testing.
- Ideal for portable and installed applications.
- Lightweight, compact 15 mm wood enclosure with internal bracing with durable polyurea top-coat finish.
- Professional-grade hardware: integrated M20 threaded pole mount plate and two-handle design for easy lifting.
The ELX series is designed to deliver an unprecedented combination of sound quality, portability and durability at its price point. All-new custom components—tested to levels far exceeding the industry norm—make ELX200 a robust workhorse capable of handling real-world abuse and professional applications beyond the capability of competitors’ products in its category.
Every aspect of ELX200 is designed for ideal results as part of the whole – the acoustical, electrical and mechanical components all work together seamlessly. The subwoofers pack powerful low-frequency output into a surprisingly compact footprint, and feature tuned 15 mm thick wood enclosures with a premium top-coat finish. The proprietary features that have made the other members of the EV portable speaker family a go-to for best-in-class performance are also present.
EV’s industry-leading quality and testing procedures yield efficient transducer design and meaningful specs, resulting in components that deliver accurate, linear response at the system’s highest output levels. Translation: loud and clear all the way up to the limit. Unified in one of the strongest full-range composite enclosures ever built by EV. The ELX200 is established as the new benchmark for toughness – both acoustically and physically; maximum efficiency with maximum toughness.
SPECIFICATIONS
| Weight Net | 58.64lbs (26.6kg) |
| Depth | 22.6″ (574mm) |
| Width | 19.96″ (507mm) |
| Height | 23.62″ (600mm) |
| Available Color | Black or White |
| Axial Sensitivity (SPL, 1 W @ 1 m) | 94dB |
| Connector Type | Dual NL4 |
| Enclosure Material | 15 mm plywood with durable polyurea top-coat finish |
| Family | ELX200 |
| Frequency Range (-10 dB) | 28 Hz – 300 Hz |
| Frequency Response (-3 dB) | 45 Hz – 200kHz |
| Grille | 18 AWG steel with powdercoat |
| HF Transducer | |
| LF Transducer | EVS-18L 457 mm (18 in) |
| Max. SPL/1m (calc) | 133 HzdB |
| Minimum Impedance | 7.2 ΩΩ |
| Nominal Impedance | 8Ω |
| Power Handling (Continuous / Peak) | 400W/1600W |
| Power Rating | 1600W |
| Recommended High-Pass Frequency | 35 HzHz |
| Shipping Weight | 67.24lbs (30.5kg) |
| Speaker Type | Subwoofer |
| Suspension | |
| Woofer Size | 18inch |
