RCF F 16XR 16-Channel Mixer with Multi-FX and Recording

Call For Price

Found this product at a lower price?

16-Channel Mixer

Description

Versatile Analogue Mixing

The RCF F 16XR Mixer picks up where the RCF’s iconic E Series left off. Based on the legacy of well-established analogue mixing, the F Series 16XR delivers high quality audio in the form of a robust, powerful, and easy-to-use mixer. A full balanced audio path from input to output, a formidable DSP FX unit, and USB connectivity ensure you’ve got everything you need for great sound right in front of you. A 3-band EQ for mono channels (and 2-band for stereo channels) allows for precision frequency shaping possibilities. While single control compressors are both powerful and easy-to-use.

24-Bit Digital Effects

The RCF F 16XR comes with a whole host of built-in digital effects. Foregoing the need for clunky external units, the RCF F 16XR provides 16 studio-quality effects ideal for a variety of performances. Choose from a selection of reverbs, delays, chorus, and flangers. And cater to any need with FX returns that can be routed to AUXs for personal monitor mixes. This mixer gives you professional effects at a moment’s notice.

USB Connectivity

Recording your shows couldn’t be easier. With high-performance USB connectivity the RCF F 16XR can record performances direct to any computer or laptop without the need for additional interfaces. Select your own USB routing, hear stereo playback, and achieve CD-quality recording. You can also plug directly into the RCF F 16XR for instant DI recording, without the need for external DI boxes. The F 16XR’s built-in Hi-Z input effectively boost low level instruments to standardised levels meaning you’re always ready to record.

Features

10 Mic preamp inputs, 4 mono line inputs
4 Stereo line inputs
PRO DSP FX onboard with 16 presets
Stereo recording and playback via USB port
6 single control compressors
Balanced main output 28 dB (Stereo XLR TRS)
Two stereo output busses and 4 aux sends (2 pre, 1 pre/post, 1 post)
60 mm faders
Internal universal power supply
Designed and engineered in Italy

Specs

Electrical specifications

FREQUENCY RESPONSE:

20 Hz ÷ 20 kHz

THD N, 20DB GAIN, 0DBU OUT (% A-WEIGHTED):

<0,02% A-Weighted

POWER SUPPLY:

Internal

VOLTAGE REQUIREMENTS:

100 V – 240 V

POWER CONSUMPTION (W):

30 W

Inputs

GAIN RANGE:

0 dB ÷ -50 dB

GAIN SELECTION:

20 dB ÷ -30 dB

HI-Z LINE INPUTS IMPEDANCE (MOHM):

1 Mohm

HI-Z LINE INPUTS:

INPUT NOISE LEVEL (DBU A-WEIGHTED):

-124 dBu A-Weighted

MIC INPUTS IMPEDANCE (KOHM):

14 kohm

LINE:

LINE INPUT IMPEDANCE (KOHM):

21 kohm

LOW CUT:

80 Hz

MIC:

PHANTOM POWER 48V:

Yes

STEREO LINE:

STEREO LINE GAIN SELECTION:

20 dB ÷ -30 dB

STEREO LINE INPUT IMPEDANCE:

14 kohm

Outputs

MAIN MIX:

CONTROL ROOM:

Yes

FX SEND:

AUX SEND:

AUX OUTPUT:

GROUP OUT:

PHONES:

Outputs specifications

MAIN OUT LEVEL (DBU):

28 dBu

AUX OUT LEVEL (DBU):

28 dBu

GROUP OUT LEVEL (DBU):

28 dBu

PHONES OUT IMPEDANCE (OHM):

150 ohm

PHONES OUT LEVEL (DBM):

10 dBm

Compressors

RCF COMPRESSORS:

n°6 Single Control Compressors on Channels 1 to 6

INPUT CHANNELS EQ:

1 Semi Parametric / 2 Shelving

DESCRIPTION:

High: /-15 dB @ 10 kHz Shelving Mid: /-15 dB @ Freq. sel. from 100Hz to 8kHz – Bell Low: /-15 dB @ 100 Hz Shelving

Auxiliary sends

AUX:

2 PRE / 1 PRE/POST

FX POST:

Internal Effects

SEND EFFECTS:

USB audio

TYPE:

PLAY TRK:

REC TRK:

SUPPORTED SAMPLE RATE (KHZ):

44.1, 48.0 kHz

Other features

FOOTSWITCH:

Yes

Standard compliance

CE MARKING:

Yes

Physical specifications

CABINET/CASE MATERIAL:

Metal

COLOR:

Black

Size

DEPTH:

406 mm / 15.98 inches

HEIGHT:

107 mm / 4.21 inches

WEIGHT:

6.4 kg / 14.11 lbs

WIDTH:

479 mm / 18.86 inches

Shipping informations

PACKAGE DEPTH:

523 mm / 20.59 inches

PACKAGE HEIGHT:

150 mm / 5.91 inches

PACKAGE WEIGHT:

7.4 kg / 16.31 lbs

PACKAGE WIDTH:

453 mm / 17.83 inches

Additional information

Weight	8 g
Dimensions	52 × 45 × 15 mm
Hybrid Condensers
Brand	RCF
