Description
The MQ60H is a wall mount monitor speaker designed to guarantee uniform coverage of a large area in order to limit the number of speakers and therefore the installation points. It is a two-way speaker with three transducers: the 5"œ woofer and the two horn-loaded dome tweeters with constant directivity are positioned in such a way as to ensure the maximum listening comfort within the area covered. Installation is carried out in two phases: first, you mount the support on the wall and make the electrical connections; when all the works are completed, you insert the speaker and make a quick connection.
Features
- 5″ woofer with 2 x 1″ dome tweeter
- Power selectable (100 V): 30 W – 20 W – 10 W – 5 W
- 88 dB sensitivity
- Colour white RAL 9016 and black RAL 9005
- Plastic body, steel grille
Specs
Acoustical specifications
FREQUENCY RESPONSE (-10DB):
100 Hz “· 19000 Hz
MAX SPL @ 1M:
109 dB
HORIZONTAL COVERAGE ANGLE:
180 °
VERTICAL COVERAGE ANGLE:
100 °
SYSTEM SENSITIVITY:
88 dB
Power section
NOMINAL IMPEDANCE (OHM):
16 ohm
POWER HANDLING:
60 W RMS
PEAK POWER HANDLING:
240 W PEAK
RECOMMENDED AMPLIFIER:
120 W
CROSSOVER FREQUENCIES:
2000 Hz
Transducers
DOME TWEETER:
2 x 1.0”
WOOFER:
5.0”
Input/Output section
INPUT CONNECTORS:
Euroblock
OUTPUT CONNECTORS:
Euroblock
CONSTANT VOLTAGE TRANSFORMER:
100 V
POWER SELECTION 1 (100 V):
30 W – 333 ohm
POWER SELECTION 2 (100 V):
20 W – 500 ohm
POWER SELECTION 3 (100 V):
10 W – 1000 ohm
POWER SELECTION 4 (100 V):
5 W – 2000 ohm
Standard compliance
CE MARKING:
Yes
Physical specifications
COLOR:
White – RAL 9016
HARDWARE:
Wall mount bracket
GRILLE:
Steel
CABINET/CASE MATERIAL:
Plastic
Size
WIDTH:
198 mm / 7.8 inches
DEPTH:
122 mm / 4.8 inches
HEIGHT:
297 mm / 11.69 inches
WEIGHT:
2.85 kg / 6.28 lbs
Shipping informations
PACKAGE WEIGHT:
3.39 kg / 7.47 lbs
PACKAGE DEPTH:
180 mm / 7.09 inches
PACKAGE WIDTH:
265 mm / 10.43 inches
PACKAGE HEIGHT:
340 mm / 13.39 inches
