Description
AM 1125 is a 120W mixer-amplifier having 4 audio inputs. Audio input 1 has Phantom power supply and get the priority over the other audio inputs through an external command or automatically thanks to the ‘VOX’ circuit. Dual RCA connectors can be used to link stereo (unbalanced) sound sources (e.g. CD – MP3 players, tuners, etc.). The amplifier output is available either for low impedance loudspeakers (min. 4 O) or 100 – 70 V constant voltage line (for loudspeakers having 100 – 70 V transformers). It can also be powered by batteries (voltage: 24 V dc), in order to ensure its proper operation even when the mains supply is unavailable.
Features
- 120W 4-inputs Mixer-Amplifier
- 4 XLR input
- VOX facility and Phantom power supply on input 1
- Audio input 3 also with dual RCA connector
- Aux input on dual RCA connector
- DUCKING Control to adjust the Aux in level
- Audio output (with RCA connector) that sends the same signal routed to the internal amplifier
- Audio input (with RCA connector) to connect an external device directly to the internal power amplifier
- AM 1125 Input for the secondary 24 V dc power supply (batteries)
- Amplifier output to loudspeakers, available as 100 / 70 V constant voltage line and Low impedance (min. 4 O)
Specs
Amplifier specifications
NUMBER OF CHANNELS:
1
POWER OUTPUT PER CHANNEL (@ 4 OHM):
120 W RMS
POWER OUTPUT (@ 100 V):
120 W RMS
FREQUENCY RESPONSE (-3DB):
60 Hz ÷ 15 kHz
DISTORTION (THD N) @ 1 KHZ NOMINAL POWER:
<1.5 %
Input section
BALANCED:
4
GENERAL PURPOSE INPUTS (GPI):
1
LINE CONNECTORS:
RCA
LINE INPUTS:
2
MIC LINE CONNECTORS:
RCA, XLR
MIC LINE INPUTS:
4
MIC LINE PHANTOM:
18 V DC
VOX: (MIC LINE):
Yes
MONO:
5
PAGING CONNECTORS:
XLR
STEREO:
2
TOTAL NUMBER OF INPUTS:
6
UNBALANCED:
6
Output section
SIGNAL OUTPUT NUMBER:
1
SIGNAL OUTPUT CONNECTORS:
RCA
POWER OUTPUT CONNECTORS:
Euroblock
Processing
TONE CONTROLS:
Yes
Controls
CONFIGURATION:
Front panel
Protections
COOLING:
Convection
SHORT CIRCUIT:
Yes
THERMAL:
Yes
DC DELAY:
Yes
FUSES:
Yes
Power requirement
OPERATING VOLTAGE:
220-240/115 V~ 50/60Hz
VOLTAGE SELECTION:
External
DC POWER:
Yes
DC POWER VALUE:
24 V
POWER CONSUMPTION:
350 W
Standard compliance
CE MARKING:
Yes
Physical specifications
CABINET/CASE MATERIAL:
Metal
COLOR:
Black
RACK MOUNTING:
19″, 2U
Size
DEPTH:
385 mm / 15.16 inches
HEIGHT:
88 mm / 3.46 inches
WEIGHT:
7.3 kg / 16.09 lbs
WIDTH:
431 mm / 16.97 inches
Shipping informations
PACKAGE DEPTH:
380 mm / 14.96 inches
PACKAGE HEIGHT:
165 mm / 6.5 inches
PACKAGE WEIGHT:
8.5 kg / 18.74 lbs
PACKAGE WIDTH:
500 mm / 19.69 inches
